Integrated tattoo needle
时间：2022-02-28 11:45
Tattoo needles can generally be divided into round needles and row needles, and round needles can be divided into three categories: 1 Tightening needle (rlbt) 2 Pine needle (RLB) 3 Relaxation needle (RSB) can be divided into four categories: 1 Single row needle (FB) 2 Row needle (M2b) 3 Round row needle (m1bc) 4 Row needle (M1B) the following describes the technical requirements of each needle.
Specification: 12 05 RLB
12: Type code (round needle and loose needle)
05: number of needles gathered together (5 needles gathered together)
RLB: Code of steel wire thickness
1.Round needle
Type | Needle blank | Tip length | Code | Solder length | technical requirement |
Tight needle | 0.33×30 | 3.5mm(Long needle tip） | RLBT | 26 mm | The soldering tin of the needle body is smooth, and the needle tip remains wrapped tightly |
Pine needle | 0.33×30 | 3mm（Long needle tip） | RLB | 26 mm | The soldering tin of the needle body is bright and clean, and the needle tip remains slightly loose |
Relaxation needle | 0.35×30 | 3.5mm（Long needle tip） | RSB-1 | 22 mm | The soldering tin of the needle body is smooth and the needle tip remains relaxed |
2.Pin
type | Needle shape | Needle blank | Tip length | Code | Solder length | technical requirement |
Row needle | One floor side by side |
0.35×30 | 3.5mm（long） | FB-1 |
20mm | One side of the needle body shall be kept bright and clean, and one side of the solder shall be kept flat |
1.5mm（short） | FB-2 | |||||
Double row needle | Two layers side by side |
0.35×30 | 3.5mm（long） | M2B-1 | 20 mm（7针） | There should be less solder on the side with more needles, and there should be a little more solder on the side with fewer needles and it should be flat |
1.5mm（short） | M2B-2 | 22.5 mm （9-13针） | ||||
Round row needle | The two layers are crossed and separated, and the head is round |
0.35×30 | 3.5mm（long） | M1BC-1 | 20 mm（5-7针） | One side of the needle shall be kept clean and bright, and the solder on the side with few needles shall be flat and bright |
1.5mm（short） | M1BC-2 | 22.5 mm （9-45针） | ||||
Pin | The two layers are crossed and separated to be parallel |
0.35×30 | 3.5mm（long） | M1B-1 | 20 mm（5-7针） | One side of the needle shall be kept clean and bright, and the solder on the side with few needles shall be flat and bright |
